SIC769ACD-T1-GE3
IC HALF BRIDGE DRIVER 35A PPAKManufacturer: Vishay Siliconix
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Vishay Siliconix SIC769ACD-T1-GE3 is a DrMOS half-bridge driver designed for synchronous buck converter applications. This surface-mount component, housed in a PowerPAK® MLP66-40 package, features a 35A output current capability and a low on-resistance of 1.7mOhm for the low-side switch and 6mOhm for the high-side switch. The device integrates a bootstrap circuit and diode emulation for enhanced performance. It offers fault protection against over-temperature, shoot-through, and undervoltage lockout (UVLO), with a status flag for monitoring. The SIC769ACD-T1-GE3 operates with a load voltage range of 3V to 16V and a supply voltage of 4.5V to 5.5V, suitable for demanding power management solutions in automotive and industrial sectors. It is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit, Diode Emulation, Status Flag |
| Packaging | Tape & Reel (TR) |
| Package / Case | PowerPAK® MLP66-40 |
| Mounting Type | Surface Mount |
| Interface | PWM |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 4.5V ~ 5.5V |
| Rds On (Typ) | 1.7mOhm LS, 6mOhm HS |
| Applications | Synchronous Buck Converters |
| Current - Output / Channel | 35A |
| Current - Peak Output | - |
| Technology | DrMOS |
| Voltage - Load | 3V ~ 16V |
| Supplier Device Package | PowerPAK® MLP66-40 |
| Fault Protection | Over Temperature, Shoot-Through, UVLO |
| Load Type | Inductive |
