SQ3989EV-T1_BE3
MOSFET 2P-CH 30V 2.5A 6TSOPManufacturer: Vishay Siliconix
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Mosfet Array 30V 2.5A (Tc) 1.67W (Tc) Surface Mount 6-TSOP
Additional Information
Series: TrenchFET®RoHS Status: unknownManufacturer Lead Time: 17 week(s)Product Status: ActivePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Mounting Type | Surface Mount |
| Configuration | 2 P-Channel (Dual) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 1.67W (Tc) |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 2.5A (Tc) |
| Input Capacitance (Ciss) (Max) @ Vds | - |
| Rds On (Max) @ Id, Vgs | 155mOhm @ 400mA, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 11.1nC @ 10V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Supplier Device Package | 6-TSOP |
| Grade | Automotive |
| Qualification | AEC-Q101 |
