SIC967ED-T1-GE3
4.5V TO 60V INPUT 6A MICROBRICKManufacturer: Vishay Siliconix
Categories: DC DC Converters
Quality Control: Learn More
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 15V 6A 4.5V - 60V Input
Additional Information
Series: microBRICK® SiC967RoHS Status: ROHS3 CompliantManufacturer Lead Time: 14 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Adjustable Output, Remote On/Off, Remote Sense |
| Packaging | Tape & Reel (TR) |
| Package / Case | 54-PowerBFQFN |
| Size / Dimension | 0.42"" L x 0.26"" W x 0.12"" H (10.6mm x 6.5mm x 3.0mm) |
| Mounting Type | Surface Mount |
| Type | Non-Isolated PoL Module |
| Operating Temperature | -40°C ~ 85°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 60V |
| Approval Agency | - |
| Efficiency | 97% |
| Current - Output (Max) | 6A |
| Supplier Device Package | PowerPAK® MLP54-A6C |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output 1 | 0.8 ~ 15V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Control Features | - |
| Number of Outputs | 1 |
| Standard Number | - |
