DG417DY-T1
IC SWITCH SPST-NCX1 35OHM 8SOICManufacturer: Vishay Siliconix
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Vishay Siliconix DG417DY-T1 is a single-pole, single-throw, normally closed (SPST-NC) analog switch designed for 1:1 multiplexer/demultiplexer applications. This component features a low on-state resistance of 35 Ohms (maximum) and a channel capacitance of 8pF for both off-state conditions. The DG417DY-T1 operates with single or dual supply voltages, supporting up to +12V single or ±15V dual supplies. Switching times are specified at a maximum of 175ns for turn-on and 145ns for turn-off. Leakage current (IS(off)) is limited to 250pA. The DG417DY-T1 is housed in an 8-SOIC package suitable for surface mounting and operates across an industrial temperature range of -40°C to 85°C. This device finds application in various industries including industrial automation, consumer electronics, and medical equipment. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 35Ohm |
| -3db Bandwidth | - |
| Supplier Device Package | 8-SOIC |
| Voltage - Supply, Single (V+) | 12V |
| Voltage - Supply, Dual (V±) | ±15V |
| Charge Injection | 60pC |
| Crosstalk | - |
| Switch Circuit | SPST - NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | - |
| Switch Time (Ton, Toff) (Max) | 175ns, 145ns |
| Channel Capacitance (CS(off), CD(off)) | 8pF, 8pF |
| Current - Leakage (IS(off)) (Max) | 250pA |
| Number of Circuits | 1 |
