PP12SR472A340B
POT 4.7K OHM 1/2W PLASTIC LINEARManufacturer: Vishay Sfernice
Categories: Rotary Potentiometers, Rheostats
Quality Control: Learn More
4.7k Ohm 1 Gang Linear Servo Mount Potentiometer 1.0 Turns Conductive Plastic 0.5W, 1/2W PC Pins
Additional Information
Series: PP12SRRoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: 21 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 4.7k |
| Power (Watts) | 0.5W, 1/2W |
| Tolerance | ±20% |
| Features | - |
| Packaging | Box |
| Temperature Coefficient | 0/ -600ppm/°C |
| Adjustment Type | Top Adjustment |
| Mounting Type | Servo Mount |
| Termination Style | PC Pins |
| Bushing Thread | - |
| Actuator Length | 0.492"" (12.50mm) |
| Actuator Type | Slotted |
| Built in Switch | None |
| Actuator Diameter | 0.125"" (3.18mm) |
| Resistive Material | Conductive Plastic |
| Taper | Linear |
| Rotation | 360° |
| Number of Gangs | 1 |
| Number of Turns | 1.0 |
