PRA135I4-5K11BBBW
PRA 135 I 4 5K11 0.1% 0.1% B WPManufacturer: Vishay Sfernice
Categories: Resistor Networks, Arrays
Quality Control: Learn More
Vishay Sfernice PRA100 (CNW) series 8-element isolated resistor network, part number PRA135I4-5K11BBBW. This surface-mount component features 5.11 kOhms resistance per element with a tight ±0.1% tolerance and ±10 ppm/°C temperature coefficient. Each element is rated for 125mW power dissipation. The network is housed in an 0805 (2012 Metric) concave package, measuring 5.40mm x 1.91mm, with a maximum seated height of 0.64mm. Operating temperature range is -55°C to 155°C. This component is suitable for applications requiring precise voltage division and current limiting in industrial and automotive environments.
Additional Information
Series: PRA100 (CNW)RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 5.11k |
| Tolerance | ±0.1% |
| Packaging | Tray |
| Power Per Element | 125mW |
| Circuit Type | Isolated |
| Number of Pins | 4 |
| Package / Case | 0805 (2012 Metric), Concave |
| Temperature Coefficient | ±10ppm/°C |
| Size / Dimension | 0.213"" L x 0.075"" W (5.40mm x 1.91mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 155°C |
| Applications | - |
| Supplier Device Package | 0805 |
| Height - Seated (Max) | 0.025"" (0.64mm) |
| Grade | - |
| Resistor Matching Ratio | ±0.1% |
| Resistor-Ratio-Drift | ±2ppm/°C |
| Number of Resistors | 8 |
| Qualification | - |
