RSO25138CR220KB00
RSO 25X138 CS U22 10% BO2NAManufacturer: Vishay Sfernice
Categories: Chassis Mount Resistors
Quality Control: Learn More
220 Ohms ±10% 160W Wirewound Chassis Mount Resistor
Additional Information
Series: RSORoHS Status: RoHS CompliantManufacturer Lead Time: 9 week(s)Product Status: ActivePackaging: BoxDownload Free CAD Model:
Technical Details:
| Power (Watts) | 160W |
| Tolerance | ±10% |
| Lead Style | Solder Lugs |
| Features | - |
| Packaging | Box |
| Package / Case | Radial, Tubular |
| Temperature Coefficient | - |
| Size / Dimension | 1.535"" Dia x 5.433"" L (39.00mm x 138.00mm) |
| Composition | Wirewound |
| Operating Temperature | -55°C ~ 200°C |
| Mounting Feature | Brackets (not included) |
| Coating, Housing Type | Vitreous Enamel Coated |
| Height - Seated (Max) | - |
| Failure Rate | - |
| Resistance | 220 Ohms |
