SFH601-3X001
OPTOISO 5.3KV TRANS W/BASE 6DIPManufacturer: Vishay Semiconductor Opto Division
Categories: Transistor, Photovoltaic Output Optoisolators
Quality Control: Learn More
The Vishay Semiconductor Opto Division SFH601-3X001 is a single-channel optocoupler featuring a transistor output with base connection. This device provides 5000Vrms isolation and is housed in a 6-DIP package suitable for through-hole mounting. Key electrical characteristics include a typical forward voltage of 1.25V and a maximum forward current of 60mA. The output transistor offers a saturation voltage of 400mV (max) and can handle up to 100V output. Current transfer ratios range from a minimum of 100% at 10mA to a maximum of 200% at 10mA. Typical rise and fall times are 2µs, with turn-on and turn-off times of 3µs and 2.3µs, respectively. This component is widely utilized in industrial control, power supplies, and medical equipment applications where robust isolation is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 6-DIP (0.300"", 7.62mm) |
| Output Type | Transistor with Base |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 100°C |
| Voltage - Forward (Vf) (Typ) | 1.25V |
| Input Type | DC |
| Current - Output / Channel | 50mA |
| Voltage - Isolation | 5000Vrms |
| Current Transfer Ratio (Min) | 100% @ 10mA |
| Vce Saturation (Max) | 400mV |
| Current Transfer Ratio (Max) | 200% @ 10mA |
| Supplier Device Package | 6-DIP |
| Voltage - Output (Max) | 100V |
| Turn On / Turn Off Time (Typ) | 3µs, 2.3µs |
| Rise / Fall Time (Typ) | 2µs, 2µs |
| Number of Channels | 1 |
| Current - DC Forward (If) (Max) | 60 mA |
