LH1546AEF
SSR RELAY SPST-NO 120MA 0-350VManufacturer: Vishay Semiconductor Opto Division
Categories: Solid State Relays (SSR)
Quality Control: Learn More
Vishay Semiconductor Opto Division LH1546 Series Solid State Relay, part number LH1546AEF. This SPST-NO (1 Form A) relay features a surface mount 4-SOP package with gull wing termination. It supports AC and DC loads with a maximum load current of 120 mA and an on-state resistance of 28 Ohms maximum. The relay operates across a load voltage range of 0 V to 350 V and requires a DC input voltage of 1.18V. Approved by BSI, cUL, FIMKO, UL, and VDE, this component is suitable for applications in telecommunications and industrial automation. Operating temperature range is -40°C to 85°C.
Additional Information
Series: LH1546RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 4-SOP (0.173"", 4.40mm) |
| Output Type | AC, DC |
| Mounting Type | Surface Mount |
| Voltage - Input | 1.18VDC |
| Circuit | SPST-NO (1 Form A) |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | Gull Wing |
| Load Current | 120 mA |
| Approval Agency | BSI, cUL, FIMKO, UL, VDE |
| Supplier Device Package | 4-SOP |
| Grade | - |
| Voltage - Load | 0 V ~ 350 V |
| On-State Resistance (Max) | 28 Ohms |
| Qualification | - |
