VEMT3700-GS18
PHOTO TRANS. SMD PLCC2Manufacturer: Vishay Semiconductor Opto Division
Categories: Phototransistors
Quality Control: Learn More
The Vishay Semiconductor Opto Division VEMT3700-GS18 is a surface-mount phototransistor designed for efficient detection of infrared light. Featuring an 850nm wavelength sensitivity and a 120° viewing angle, this component is housed in a compact 2-SMD, J-Lead package. It offers a maximum collector current (Ic) of 50 mA and a low dark current (Id) of 200 nA, ensuring reliable performance in various light sensing applications. With a maximum power dissipation of 100 mW and an operating temperature range of -40°C to 100°C, the VEMT3700-GS18 is suitable for use in automotive, industrial automation, and consumer electronics sectors. This component is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, J-Lead |
| Wavelength | 850nm |
| Mounting Type | Surface Mount |
| Orientation | Top View |
| Operating Temperature | -40°C ~ 100°C |
| Viewing Angle | 120° |
| Current - Dark (Id) (Max) | 200 nA |
| Grade | - |
| Current - Collector (Ic) (Max) | 50 mA |
| Power - Max | 100 mW |
| Qualification | - |
