6N137A-X017T

OPTOISO 5KV 1CH OPEN COLL 8SMD

Manufacturer: Vishay Semiconductor Opto Division

Categories: Logic Output Optoisolators

Quality Control: Learn More

The Vishay Semiconductor Opto Division 6N137A-X017T is a single-channel, high-speed optoisolator featuring an open-collector output. This component provides 5000Vrms of isolation and boasts a common mode transient immunity of 1kV/µs. It operates with a data rate of 10MBd and a supply voltage range of 4.5V to 5.5V. The device is supplied in an 8-SMD, gull-wing package suitable for surface mounting. Typical applications include industrial automation, power supplies, and telecommunications equipment where robust electrical isolation is critical. Propagation delays are specified as a maximum of 75ns for both tpLH and tpHL, with typical rise and fall times of 27ns and 10ns respectively. The forward current is rated up to 20mA, and the output current per channel can reach 50mA. This component is supplied on tape and reel.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:
Technical Details:
PackagingTape & Reel (TR)
Package / Case8-SMD, Gull Wing
Output TypeOpen Collector
Mounting TypeSurface Mount
Operating Temperature-40°C ~ 85°C
Voltage - Supply4.5V ~ 5.5V
Voltage - Forward (Vf) (Typ)1.35V
Data Rate10MBd
Input TypeDC
Voltage - Isolation5000Vrms
Current - DC Forward (If) (Max)20mA
Inputs - Side 1/Side 21/0
Supplier Device Package8-SMD
Rise / Fall Time (Typ)27ns, 10ns
Common Mode Transient Immunity (Min)1kV/µs
Propagation Delay tpLH / tpHL (Max)75ns, 75ns
Number of Channels1
Current - Output / Channel50 mA
