VLMK3100-GS18
LED RED CLEAR 2PLCC SMDManufacturer: Vishay Semiconductor Opto Division
Categories: LED Indication - Discrete
Quality Control: Learn More
Vishay Semiconductor Opto Division VLM3 series VLMK3100-GS18 is a red, clear lens LED designed for surface mount applications. This 630nm dominant wavelength component features a 1.9V typical forward voltage and a 50mcd millicandela rating at 10mA test current. The 2-PLCC package, also referred to as 2-SMD, J-Lead, offers a 3.00mm x 2.80mm footprint with a maximum height of 1.85mm. Its clear, round lens with a flat top provides a 120° viewing angle. This component is commonly utilized in industrial automation, consumer electronics, and automotive signaling applications. It is supplied in Tape & Reel packaging.
Additional Information
Series: VLM3RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, J-Lead |
| Color | Red |
| Size / Dimension | 3.00mm L x 2.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 50mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.9V |
| Lens Color | - |
| Current - Test | 10mA |
| Viewing Angle | 120° |
| Height (Max) | 1.85mm |
| Wavelength - Peak | 643nm |
| Wavelength - Dominant | 630nm |
| Supplier Device Package | 2-PLCC |
| Lens Transparency | Clear |
| Lens Style | Round with Flat Top |
| Lens Size | 2.40mm Dia |
