VLMG31K1M2-GS18
LED GREEN CLEAR 2PLCC SMDManufacturer: Vishay Semiconductor Opto Division
Categories: LED Indication - Discrete
Quality Control: Learn More
Vishay Semiconductor Opto Division VLMG31 series Green LED, part number VLMG31K1M2-GS18, offers a 569nm dominant wavelength with a peak wavelength of 565nm. This surface-mount component is housed in a 2-PLCC package, specifically a 2-SMD, J-Lead configuration, measuring 3.00mm L x 2.80mm W with a maximum height of 1.85mm. The clear lens features a round with flat top style, with a diameter of 2.40mm. Designed for indication, this LED provides 18mcd luminous intensity at a typical forward voltage of 2.2V and a test current of 10mA, with a broad 120° viewing angle. It is supplied on tape and reel. Applications include automotive lighting, industrial control panels, and consumer electronics.
Additional Information
Series: VLMG31RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, J-Lead |
| Color | Green |
| Size / Dimension | 3.00mm L x 2.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 18mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | - |
| Current - Test | 10mA |
| Viewing Angle | 120° |
| Height (Max) | 1.85mm |
| Wavelength - Peak | 565nm |
| Wavelength - Dominant | 569nm |
| Supplier Device Package | 2-PLCC |
| Lens Transparency | Clear |
| Lens Style | Round with Flat Top |
| Lens Size | 2.40mm Dia |
