VLCS5230
LED RED CLEAR 5MM T/HManufacturer: Vishay Semiconductor Opto Division
Categories: LED Indication - Discrete
Quality Control: Learn More
Vishay Semiconductor Opto Division VLC.52 series red LED, part number VLCS5230. This through-hole component features a 624nm dominant wavelength and 631nm peak wavelength, providing clear red illumination with a 30° viewing angle. Rated for 50mA test current, it exhibits a typical forward voltage of 2.2V and a luminous intensity of 7500mcd. The 5.80mm diameter, colorless, clear dome-shaped lens is housed in a standard radial package suitable for bulk packaging. This Vishay LED is commonly utilized in industrial automation, medical equipment, and automotive lighting applications for discrete indication.
Additional Information
Series: VLC.52RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 7500mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | Colorless |
| Current - Test | 50mA |
| Viewing Angle | 30° |
| Height (Max) | 12.70mm |
| Wavelength - Peak | 631nm |
| Wavelength - Dominant | 624nm |
| Supplier Device Package | 5mm |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5.80mm Dia |
Request a Quote
