productimage

TLVH42N2Q2

LED RED CLEAR 3MM T/H

Manufacturer: Vishay Semiconductor Opto Division

Categories: LED Indication - Discrete

Quality Control: Learn More

Vishay Semiconductor Opto Division TLV.420 series red LED, part number TLVH42N2Q2. This through-hole mounted, 3mm T-1 package LED features a clear lens with a domed top for a wide 170° viewing angle. Emitting at a dominant wavelength of 619nm and a peak wavelength of 635nm, it provides a typical forward voltage of 2.4V and a luminous intensity of 74mcd at a test current of 15mA. This discrete LED is suitable for indication applications across industrial, automotive, and consumer electronics sectors.

Additional Information

Series: TLV.420RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Bulk
Technical Details:
Features-
PackagingBulk
Package / CaseRadial
ColorRed
Size / Dimension-
Mounting TypeThrough Hole
Millicandela Rating74mcd
ConfigurationStandard
Voltage - Forward (Vf) (Typ)2.4V
Lens Color-
Current - Test15mA
Viewing Angle170°
Height (Max)4.90mm
Wavelength - Peak635nm
Wavelength - Dominant619nm
Supplier Device Package3mm
Lens TransparencyClear
Lens StyleRound with Domed Top
Lens Size3mm, T-1
