TLHY4438
LED YELLOW DIFFUSED T-1 T/HManufacturer: Vishay Semiconductor Opto Division
Categories: LED Indication - Discrete
Quality Control: Learn More
Vishay Semiconductor Opto Division TLH.44 series Yellow LED, part number TLHY4438. This diffused, T-1 package LED emits yellow light at a dominant wavelength of 587nm and a peak wavelength of 585nm. It features a forward voltage of 2.4V (typical) and a luminous intensity of 13mcd at a test current of 10mA. The TLHY4438 utilizes a through-hole mounting type with a radial package, a round, domed top lens, and a 60° viewing angle. This component is suitable for general indication applications across various industries.
Additional Information
Series: TLH.44RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Yellow |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 13mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.4V |
| Lens Color | - |
| Current - Test | 10mA |
| Viewing Angle | 60° |
| Height (Max) | 6.10mm |
| Wavelength - Peak | 585nm |
| Wavelength - Dominant | 587nm |
| Supplier Device Package | T-1 |
| Lens Transparency | Diffused |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
