TLHE4900
LED YELLOW CLEAR 3MM T/HManufacturer: Vishay Semiconductor Opto Division
Categories: LED Indication - Discrete
Quality Control: Learn More
Vishay Semiconductor Opto Division TLHE4900 is a yellow, 588nm (dominant) LED designed for through-hole mounting. This discrete indicator features a clear, domed 3mm lens and a standard radial package. With a typical forward voltage of 1.9V and a forward current of 10mA, the TLHE4900 achieves a luminous intensity of 300mcd. Its 32° viewing angle makes it suitable for various indication applications across industrial, consumer, and automotive sectors. The component is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Yellow |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 300mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.9V |
| Lens Color | - |
| Current - Test | 10mA |
| Viewing Angle | 32° |
| Height (Max) | 6.40mm |
| Wavelength - Peak | 590nm |
| Wavelength - Dominant | 588nm |
| Supplier Device Package | 3mm |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
