VOW3120-X017T

OPTOISO 5.3KV 1CH GATE DVR 8SMD

Manufacturer: Vishay Semiconductor Opto Division

Categories: Isolators - Gate Drivers

Quality Control: Learn More

2.5A Gate Driver Optical Coupling 5300Vrms 1 Channel 8-SMD

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:
Technical Details:
PackagingTape & Reel (TR)
Package / Case8-SMD, Gull Wing
Mounting TypeSurface Mount
Operating Temperature-40°C ~ 100°C
Voltage - Forward (Vf) (Typ)1.36V
Current - Peak Output2.5A
TechnologyOptical Coupling
Current - Output High, Low2.5A, 2.5A
Voltage - Isolation5300Vrms
Approval AgencyCQC, cUR, UR VDE
Supplier Device Package8-SMD
Rise / Fall Time (Typ)100ns, 100ns
Common Mode Transient Immunity (Min)25kV/µs
Propagation Delay tpLH / tpHL (Max)500ns, 500ns
Pulse Width Distortion (Max)300ns
Number of Channels1
Current - DC Forward (If) (Max)25 mA
Voltage - Output Supply15V ~ 32V
