GSOT24-HT3-GS08
TVS DIODE 24VWM 47VC LLP75-3BManufacturer: Vishay General Semiconductor - Diodes Division
Categories: TVS Diodes
Quality Control: Learn More
Vishay General Semiconductor - Diodes Division TVS Diode, part number GSOT24-HT3-GS08, is a unidirectional transient voltage suppressor designed for surface mount applications. This AEC-Q101 qualified component offers a reverse standoff voltage of 24V, with a minimum breakdown voltage of 27V. It features a clamping voltage of 47V at a peak pulse current of 5A (8/20µs), providing a peak pulse power dissipation of 235W. The GSOT24-HT3-GS08 is housed in a compact LLP75-3B (3-WDFN) package, with a capacitance of 65pF at 1MHz. Operating across a temperature range of -40°C to 125°C, this diode is suitable for automotive applications requiring robust protection.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 3-WDFN |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Applications | - |
| Capacitance @ Frequency | 65pF @ 1MHz |
| Current - Peak Pulse (10/1000µs) | 5A (8/20µs) |
| Voltage - Reverse Standoff (Typ) | 24V (Min) |
| Supplier Device Package | LLP75-3B |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 27V |
| Voltage - Clamping (Max) @ Ipp | 47V |
| Power - Peak Pulse | 235W |
| Power Line Protection | No |
| Grade | Automotive |
| Qualification | AEC-Q101 |
