ZGL41-150-E3/96
DIODE ZENER 150V 1W GL41Manufacturer: Vishay General Semiconductor - Diodes Division
Categories: Single Zener Diodes
Quality Control: Learn More
Vishay General Semiconductor - Diodes Division Zener Diode, part number ZGL41-150-E3-96, offers a 150V nominal breakdown voltage with a 1W power rating. This device features a ±10% tolerance and a maximum forward voltage of 1.5V at 200mA. The Zener impedance (Zzt) is specified at 600 Ohms maximum, with a reverse leakage current of 1 µA at 114V. Designed for surface mounting, it is housed in a DO-213AB (GL41) MELF package and supplied on tape and reel. The operating temperature range is -55°C to 150°C. This component is widely utilized in power supply regulation and voltage clamping applications across industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Tolerance | ±10% |
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-213AB, MELF |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C |
| Voltage - Zener (Nom) (Vz) | 150 V |
| Impedance (Max) (Zzt) | 600 Ohms |
| Supplier Device Package | DO-213AB (GL41) |
| Power - Max | 1 W |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 200 mA |
| Current - Reverse Leakage @ Vr | 1 µA @ 114 V |
