MMSZ4690-HE3-18
DIODE ZENER 5.6V 500MW SOD123Manufacturer: Vishay General Semiconductor - Diodes Division
Categories: Single Zener Diodes
Quality Control: Learn More
Vishay General Semiconductor - Diodes Division MMSZ4690-HE3-18 is a 5.6V Zener diode with a power dissipation of 500mW. This AEC-Q101 qualified component features a ±5% voltage tolerance and a low reverse leakage of 10 µA at 4V. Designed for surface mounting, it is housed in a compact SOD-123 package. The operating temperature range is -55°C to 150°C. This component is suitable for automotive applications, offering reliable voltage regulation in demanding environments.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Tolerance | ±5% |
| Packaging | Tape & Reel (TR) |
| Package / Case | SOD-123 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C |
| Voltage - Zener (Nom) (Vz) | 5.6 V |
| Supplier Device Package | SOD-123 |
| Grade | Automotive |
| Power - Max | 500 mW |
| Current - Reverse Leakage @ Vr | 10 µA @ 4 V |
| Qualification | AEC-Q101 |
