VS-30ETU12THN3
DIODE GEN PURP 30A TO220ACManufacturer: Vishay General Semiconductor - Diodes Division
Categories: Single Diodes
Quality Control: Learn More
Vishay General Semiconductor - Diodes Division VS-30ETU12THN3 is a FRED Pt® series fast recovery diode. This component boasts a 30A average rectified current (Io) and a 2.68V maximum forward voltage (Vf) at 30A. It features a reverse leakage current of 145 µA at 1200V and a reverse recovery time (trr) of 220 ns. Designed for demanding applications, it operates within a junction temperature range of -55°C to 175°C. The TO-220AC through-hole package facilitates easy integration into circuit designs. This diode meets AEC-Q101 qualification, ensuring suitability for automotive applications.
Additional Information
Series: FRED Pt®RoHS Status: ROHS3 CompliantManufacturer Lead Time: 14 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-2 |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 220 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 30A |
| Supplier Device Package | TO-220AC |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Grade | Automotive |
| Voltage - Forward (Vf) (Max) @ If | 2.68 V @ 30 A |
| Current - Reverse Leakage @ Vr | 145 µA @ 1200 V |
| Qualification | AEC-Q101 |
