UGF15HTHE3/45
DIODE GEN PURP 500V 15A ITO220ACManufacturer: Vishay General Semiconductor - Diodes Division
Categories: Single Diodes
Quality Control: Learn More
Vishay General Semiconductor - Diodes Division UGF15HTHE3-45 is a fast recovery general-purpose diode with a maximum repetitive peak reverse voltage of 500 V. This device features an average rectified forward current handling capability of 15 A and a low reverse leakage current of 30 µA at 500 V. The forward voltage drop at 15 A is a maximum of 1.75 V. Designed for through-hole mounting, it utilizes the ITO-220AC package, offering an isolated tab for enhanced thermal management. The operating junction temperature range is from -55°C to 150°C, and the reverse recovery time (trr) is specified at 50 ns. This component is suitable for applications in power supply rectification, inverters, and general-purpose high-frequency rectification where efficient switching and robust performance are critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-2 Full Pack, Isolated Tab |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 50 ns |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 15A |
| Supplier Device Package | ITO-220AC |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 500 V |
| Voltage - Forward (Vf) (Max) @ If | 1.75 V @ 15 A |
| Current - Reverse Leakage @ Vr | 30 µA @ 500 V |
