SBLF1040-E3/45
DIODE SCHOTTKY 40V 10A ITO220ABManufacturer: Vishay General Semiconductor - Diodes Division
Categories: Single Diodes
Quality Control: Learn More
Vishay General Semiconductor - Diodes Division SBLF1040-E3-45 is a Schottky diode designed for high-efficiency rectification. This component features a 40V reverse voltage rating and a maximum forward voltage of 600mV at 10A. With an average rectified current capability of 10A, it exhibits low leakage current, specified at 1mA at 40V. The device operates across a junction temperature range of -40°C to 125°C. Its construction, utilizing Schottky technology, ensures fast switching speeds. The SBLF1040-E3-45 is housed in an isolated tab TO-220AB package, facilitating through-hole mounting. This diode is commonly employed in power supply applications, voltage clamping, and polarity protection circuits within the automotive and industrial sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 Full Pack, Isolated Tab |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 10A |
| Supplier Device Package | ITO-220AB |
| Operating Temperature - Junction | -40°C ~ 125°C |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Voltage - Forward (Vf) (Max) @ If | 600 mV @ 10 A |
| Current - Reverse Leakage @ Vr | 1 mA @ 40 V |
