ES07B-GS18
DIODE GEN PURP 100V 1.2A DO219ABManufacturer: Vishay General Semiconductor - Diodes Division
Categories: Single Diodes
Quality Control: Learn More
Diode 100 V 1.2A Surface Mount DO-219AB (SMF)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 11 week(s)Product Status: ActivePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | DO-219AB |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 25 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 4pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 1.2A |
| Supplier Device Package | DO-219AB (SMF) |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 980 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 100 V |
