VS-25TTS12-M3
SCR 1.2KV 25A TO220ABManufacturer: Vishay General Semiconductor - Diodes Division
Categories: SCRs
Quality Control: Learn More
SCR 1.2 kV 25 A Standard Recovery Through Hole TO-220-3
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| SCR Type | Standard Recovery |
| Operating Temperature | -40°C ~ 125°C |
| Current - Hold (Ih) (Max) | 150 mA |
| Current - Gate Trigger (Igt) (Max) | 45 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 270A @ 50Hz |
| Current - On State (It (AV)) (Max) | 16 A |
| Voltage - Gate Trigger (Vgt) (Max) | 2 V |
| Voltage - On State (Vtm) (Max) | 1.25 V |
| Current - Off State (Max) | 500 µA |
| Supplier Device Package | TO-220-3 |
| Current - On State (It (RMS)) (Max) | 25 A |
| Voltage - Off State | 1.2 kV |
Request a Quote
