113CNQ100ASM
DIODE ARR SCHOTT 100V 55A D618SMManufacturer: Vishay General Semiconductor - Diodes Division
Categories: Diode Arrays
Quality Control: Learn More
Vishay General Semiconductor - Diodes Division 113CNQ100ASM is a Schottky diode array featuring a common cathode configuration. This through-hole component offers a maximum DC reverse voltage of 100V and an average rectified current of 55A per diode. The forward voltage drop is specified at 810mV at 55A. With a reverse leakage of 1mA at 100V, this device is suitable for applications requiring efficient rectification. The D-61-8-SM package provides robust thermal performance with an operating junction temperature range of -55°C to 175°C. This diode array finds application in power supply rectification, reverse polarity protection, and high-frequency switching circuits across industrial and automotive sectors.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | D-61-8-SM |
| Mounting Type | Through Hole |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Diode Configuration | 1 Pair Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 55A |
| Supplier Device Package | D-61-8-SM |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 100 V |
| Voltage - Forward (Vf) (Max) @ If | 810 mV @ 55 A |
| Current - Reverse Leakage @ Vr | 1 mA @ 100 V |
