BU15085S-E3/45
BRIDGE RECT 1P 800V 3.4A BU-5SManufacturer: Vishay General Semiconductor - Diodes Division
Categories: Bridge Rectifiers
Quality Control: Learn More
Vishay General Semiconductor - Diodes Division BU15085S-E3-45 is a single-phase bridge rectifier designed for robust power applications. This component features a maximum repetitive peak reverse voltage of 800V and an average rectified forward current (Io) of 3.4A. It exhibits a low reverse leakage current of 5 µA at 800V and a forward voltage drop (Vf) of 1.05V at 7.5A. The BU15085S-E3-45 utilizes standard rectifier technology and is housed in a 4-SIP, BU-5S package, specifically the isoCINK+™ variant, facilitating through-hole mounting. Its operating temperature range is -55°C to 150°C (TJ). This bridge rectifier is commonly employed in industrial power supplies, automotive electronics, and consumer appliances where reliable AC to DC conversion is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 4-SIP, BU-5S |
| Mounting Type | Through Hole |
| Diode Type | Single Phase |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | Standard |
| Supplier Device Package | isoCINK+™ BU-5S |
| Voltage - Peak Reverse (Max) | 800 V |
| Current - Average Rectified (Io) | 3.4 A |
| Voltage - Forward (Vf) (Max) @ If | 1.05 V @ 7.5 A |
| Current - Reverse Leakage @ Vr | 5 µA @ 800 V |
