IHSM4825ER3R3L
FIXED IND 3.3UH 4.6A 38 MOHM SMDManufacturer: Vishay Dale
Categories: Fixed Inductors
Quality Control: Learn More
Vishay Dale IHSM-4825 Fixed Inductor, part number IHSM4825ER3R3L, offers 3.3 µH inductance with a ±15% tolerance. This unshielded, surface-mount component features a current rating of 4.6 A and a saturation current (Isat) of 2.4 A. The maximum DC resistance is 38 mOhm. Constructed with a ferrite core, it operates within a temperature range of -55°C to 125°C. The dimensions are 0.540" L x 0.250" W (13.72mm x 6.35mm), with a maximum seated height of 0.225" (5.72mm). Packaged on tape and reel, this inductor is utilized in power supply and DC-DC converter applications across various industrial sectors.
Additional Information
Series: IHSM-4825RoHS Status: ROHS3 CompliantManufacturer Lead Time: 41 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±15% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.540"" L x 0.250"" W (13.72mm x 6.35mm) |
| Mounting Type | Surface Mount |
| Shielding | Unshielded |
| Type | - |
| Operating Temperature | -55°C ~ 125°C |
| DC Resistance (DCR) | 38mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Current - Saturation (Isat) | 2.4A |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 1 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.225"" (5.72mm) |
| Inductance | 3.3 µH |
| Current Rating (Amps) | 4.6 A |
