IHSM4825ER101L
FIXED IND 100UH 730MA 672MOHM SMManufacturer: Vishay Dale
Categories: Fixed Inductors
Quality Control: Learn More
The Vishay Dale IHSM-4825ER101L is a fixed inductor from the IHSM-4825 series, offering 100 µH of inductance with a ±15% tolerance. This unshielded, surface-mount component features a current rating of 730 mA and a DC resistance (DCR) of 672 mOhm maximum. Its ferrite core is designed for efficient operation. The inductor's dimensions are 13.72 mm x 6.35 mm with a maximum seated height of 5.72 mm. It operates within a temperature range of -55°C to 125°C and is supplied on tape and reel. This component is suitable for applications in automotive and industrial power management systems.
Additional Information
Series: IHSM-4825RoHS Status: ROHS3 CompliantManufacturer Lead Time: 41 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±15% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.540"" L x 0.250"" W (13.72mm x 6.35mm) |
| Mounting Type | Surface Mount |
| Shielding | Unshielded |
| Type | - |
| Operating Temperature | -55°C ~ 125°C |
| DC Resistance (DCR) | 672mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Current - Saturation (Isat) | 500mA |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 1 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.225"" (5.72mm) |
| Inductance | 100 µH |
| Current Rating (Amps) | 730 mA |
