IHLP5050FDER100M0P
FIXED IND 10UH 12.2A 17.2 MOHM SManufacturer: Vishay Dale
Categories: Fixed Inductors
Quality Control: Learn More
10 µH Shielded Molded Inductor 12.2 A 17.2mOhm Max Nonstandard
Additional Information
Series: IHLP-5050FD-0PRoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.530"" L x 0.508"" W (13.46mm x 12.90mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Molded |
| Operating Temperature | -55°C ~ 155°C |
| DC Resistance (DCR) | 17.2mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 10.9MHz |
| Ratings | - |
| Current - Saturation (Isat) | 16.1A |
| Material - Core | Metal Composite |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.252"" (6.40mm) |
| Inductance | 10 µH |
| Current Rating (Amps) | 12.2 A |
