IHLP2525CZER8R2M01
FIXED IND 8.2UH 4A 68 MOHM SMDManufacturer: Vishay Dale
Categories: Fixed Inductors
Quality Control: Learn More
8.2 µH Shielded Molded Inductor 4 A 68mOhm Max Nonstandard
Additional Information
Series: IHLP-2525CZ-01RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.270"" L x 0.255"" W (6.86mm x 6.47mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Molded |
| Operating Temperature | -55°C ~ 125°C |
| DC Resistance (DCR) | 68mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Current - Saturation (Isat) | 7.5A |
| Material - Core | - |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.118"" (3.00mm) |
| Inductance | 8.2 µH |
| Current Rating (Amps) | 4 A |
Request a Quote
