VSOR1601103JTF
THIN FILM RES ARRAY 16 PIN BUSSEManufacturer: Vishay Dale Thin Film
Categories: Resistor Networks, Arrays
Quality Control: Learn More
Vishay Dale Thin Film VSOR series resistor array, part number VSOR1601103JTF. This 16-pin SOIC package features a bussed circuit configuration with 15 individual 10k Ohm resistors. Each element is rated for 100mW of power dissipation and exhibits a tolerance of ±5%. The temperature coefficient is ±100ppm/°C, with an operating temperature range spanning -55°C to 125°C. The device dimensions are 0.390" L x 0.152" W (9.91mm x 3.86mm), with a seated height of 0.069" (1.76mm). This surface mount component is supplied on tape and reel. It is utilized in applications requiring precise and stable resistance networks.
Additional Information
Series: VSORRoHS Status: ROHS3 CompliantManufacturer Lead Time: 42 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 10k |
| Tolerance | ±5% |
| Packaging | Tape & Reel (TR) |
| Power Per Element | 100mW |
| Circuit Type | Bussed |
| Number of Pins | 16 |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Temperature Coefficient | ±100ppm/°C |
| Size / Dimension | 0.390"" L x 0.152"" W (9.91mm x 3.86mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Applications | - |
| Supplier Device Package | 16-SOIC |
| Height - Seated (Max) | 0.069"" (1.76mm) |
| Grade | - |
| Resistor Matching Ratio | - |
| Resistor-Ratio-Drift | - |
| Number of Resistors | 15 |
| Qualification | - |
