MAL218697607E3
CAP ALUM POLY 120UF 20% 25V SMDManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: Polymer Capacitors
Quality Control: Learn More
120 µF 25 V Aluminum - Polymer Capacitors Radial, Can - SMD 25mOhm 2000 Hrs @ 125°C
Additional Information
Series: 186 CPNTRoHS Status: ROHS3 CompliantManufacturer Lead Time: 24 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.315"" Dia (8.00mm) |
| Mounting Type | Surface Mount |
| Type | Polymer |
| Operating Temperature | -55°C ~ 125°C |
| Applications | Automotive |
| Lead Spacing | - |
| Ratings | - |
| ESR (Equivalent Series Resistance) | 25mOhm |
| Lifetime @ Temp. | 2000 Hrs @ 125°C |
| Surface Mount Land Size | 0.315"" L x 0.315"" W (8.00mm x 8.00mm) |
| Height - Seated (Max) | 0.472"" (12.00mm) |
| Capacitance | 120 µF |
| Voltage - Rated | 25 V |
| Ripple Current @ High Frequency | 3.8 A @ 100 kHz |
