NTCSMELFXX303JT
THERM NTC 30KOHM 3997K DO213AAManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: NTC Thermistors
Quality Control: Learn More
The Vishay Beyschlag/Draloric/BC Components 2322 series NTC thermistor, part number NTCSMELFXX303JT, offers a resistance of 30 kOhms at 25°C with a resistance tolerance of ±5%. This component features a B25/85 value of 3997K and a B value tolerance of ±1.3%. Designed for surface mount applications, it is housed in a DO-213AA package and can operate across a temperature range of -40°C to 200°C. With a maximum power dissipation of 100 mW, this thermistor is suitable for applications in automotive, industrial, and consumer electronics sectors requiring precise temperature sensing and compensation. The NTCSMELFXX303JT is supplied on tape and reel (TR).
Additional Information
Series: 2322RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-213AA |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 200°C |
| B0/50 | - |
| B25/50 | - |
| B25/85 | 3997K |
| B25/100 | - |
| B Value Tolerance | ±1.3% |
| Resistance in Ohms @ 25°C | 30k |
| Resistance Tolerance | ±5% |
| B25/75 | - |
| Length - Lead Wire | - |
| Power - Max | 100 mW |
