MAL222051009E3
CAP ALUM 60F 2.7V 1000HManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: Electric Double Layer Capacitors (EDLC), Supercapacitors
Quality Control: Learn More
60 F (EDLC) Supercapacitor 2.7 V Radial, Can 9mOhm @ 1kHz 1000 Hrs @ 85°C
Additional Information
Series: ENYCAP™ 220 EDLC, Automotive, AEC-Q200RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | -20%, +50% |
| Packaging | Box |
| Package / Case | Radial, Can |
| Size / Dimension | 0.709"" Dia (18.00mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Lead Spacing | 0.295"" (7.50mm) |
| Termination | PC Pins |
| ESR (Equivalent Series Resistance) | 9mOhm @ 1kHz |
| Lifetime @ Temp. | 1000 Hrs @ 85°C |
| Height - Seated (Max) | 1.673"" (42.50mm) |
| Capacitance | 60 F |
| Voltage - Rated | 2.7 V |
