MAL216099103E3
CAP ALUM 220UF 20% 50V SMDManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: Aluminum Electrolytic Capacitors
Quality Control: Learn More
220 µF 50 V Aluminum Electrolytic Capacitors Radial, Can - SMD 1250 Hrs @ 150°C
Additional Information
Series: 160 CLARoHS Status: ROHS3 CompliantManufacturer Lead Time: 14 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.492"" Dia (12.50mm) |
| Polarization | Polar |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C |
| Applications | Automotive |
| Lead Spacing | - |
| Ratings | AEC-Q200 |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1250 Hrs @ 150°C |
| Surface Mount Land Size | 0.508"" L x 0.508"" W (12.90mm x 12.90mm) |
| Height - Seated (Max) | 0.689"" (17.50mm) |
| Capacitance | 220 µF |
| Voltage - Rated | 50 V |
| Impedance | 85 mOhms |
| Ripple Current @ High Frequency | 550 mA @ 100 kHz |
Request a Quote
