MAL215786331E3
CAP ALUM 330UF 20% 400V SNAP THManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: Aluminum Electrolytic Capacitors
Quality Control: Learn More
330 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 3 Lead 700mOhm @ 100Hz 5000 Hrs @ 85°C
Additional Information
Series: 157 PUM-SIRoHS Status: ROHS3 CompliantManufacturer Lead Time: 14 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Bulk |
| Package / Case | Radial, Can - Snap-In - 3 Lead |
| Size / Dimension | 1.378"" Dia (35.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Operating Temperature | -25°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | 0.394"" (10.00mm) |
| Ratings | - |
| ESR (Equivalent Series Resistance) | 700mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 85°C |
| Surface Mount Land Size | - |
| Height - Seated (Max) | 1.260"" (32.00mm) |
| Capacitance | 330 µF |
| Voltage - Rated | 400 V |
| Impedance | 525 mOhms |
| Ripple Current @ Low Frequency | 1.76 A @ 120 Hz |
Request a Quote
