2222 085 67478
CAP ALUM 4.7UF 20% 40V SMDManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: Aluminum Electrolytic Capacitors
Quality Control: Learn More
The Vishay Beyschlag/Draloric/BC Components 085 CS series aluminum electrolytic capacitor, part number 2222-085-67478, offers a capacitance of 4.7 µF with a tolerance of ±20% and a voltage rating of 40 V. This nonstandard SMD component features an Equivalent Series Resistance (ESR) of 54 Ohms and an impedance of 15 Ohms. Designed for general-purpose applications, it has a rated lifetime of 1500 hours at 85°C and operates within a temperature range of -40°C to 85°C. The capacitor's dimensions are 11.90mm in length and 3.70mm in width, with a seated height of 3.90mm. Its surface mount land size matches its overall dimensions. The component is supplied on tape and reel (TR) packaging. This component is commonly utilized in industrial and consumer electronics.
Additional Information
Series: 085 CSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard SMD |
| Size / Dimension | 0.469"" L x 0.146"" W (11.90mm x 3.70mm) |
| Polarization | - |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | - |
| Ratings | - |
| ESR (Equivalent Series Resistance) | 54Ohm |
| Lifetime @ Temp. | 1500 Hrs @ 85°C |
| Surface Mount Land Size | 0.469"" L x 0.146"" W (11.90mm x 3.70mm) |
| Height - Seated (Max) | 0.154"" (3.90mm) |
| Capacitance | 4.7 µF |
| Voltage - Rated | 40 V |
| Impedance | 15 Ohms |
| Ripple Current @ High Frequency | 23.4 mA @ 10 kHz |
