2222 085 67228
CAP ALUM 2.2UF 20% 40V SMDManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: Aluminum Electrolytic Capacitors
Quality Control: Learn More
Vishay Beyschlag/Draloric/BC Components 085 CS series aluminum electrolytic capacitor, part number 2222-085-67228, offers a 2.2 µF capacitance with a 40 V voltage rating and ±20% tolerance. This nonstandard SMD component features an equivalent series resistance of 120 Ohms and an impedance of 32 Ohms. Designed for general-purpose applications, it provides a lifetime of 1500 hours at 85°C and operates within a temperature range of -40°C to 85°C. The capacitor's dimensions are 0.346" L x 0.146" W (8.80mm x 3.70mm) with a seated height of 0.154" (3.90mm). It is supplied in Tape & Reel packaging. This component is suitable for use in consumer electronics and industrial power supply applications requiring reliable filtering and energy storage.
Additional Information
Series: 085 CSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard SMD |
| Size / Dimension | 0.346"" L x 0.146"" W (8.80mm x 3.70mm) |
| Polarization | - |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | - |
| Ratings | - |
| ESR (Equivalent Series Resistance) | 120Ohm |
| Lifetime @ Temp. | 1500 Hrs @ 85°C |
| Surface Mount Land Size | 0.346"" L x 0.146"" W (8.80mm x 3.70mm) |
| Height - Seated (Max) | 0.154"" (3.90mm) |
| Capacitance | 2.2 µF |
| Voltage - Rated | 40 V |
| Impedance | 32 Ohms |
| Ripple Current @ High Frequency | 12.6 mA @ 10 kHz |
Request a Quote
