2222 085 65478
CAP ALUM 4.7UF 20% 16V SMDManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: Aluminum Electrolytic Capacitors
Quality Control: Learn More
Vishay Beyschlag/Draloric/BC Components 085 CS series aluminum electrolytic capacitor with a capacitance of 4.7 µF and a voltage rating of 16 V. This nonstandard SMD component features an Equivalent Series Resistance (ESR) of 68 Ohms and an impedance of 26 Ohms. It is rated for 1500 hours of operation at 85°C and operates across a temperature range of -40°C to 85°C. The capacitor has a ripple current capability of 13.5 mA at 10 kHz. Its dimensions are 0.346 inches (8.80mm) in length and 0.146 inches (3.70mm) in width, with a seated height of 0.154 inches (3.90mm). This component is suitable for general-purpose applications and is supplied in tape and reel packaging. Part number 2222-085-65478.
Additional Information
Series: 085 CSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard SMD |
| Size / Dimension | 0.346"" L x 0.146"" W (8.80mm x 3.70mm) |
| Polarization | - |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | - |
| Ratings | - |
| ESR (Equivalent Series Resistance) | 68Ohm |
| Lifetime @ Temp. | 1500 Hrs @ 85°C |
| Surface Mount Land Size | 0.346"" L x 0.146"" W (8.80mm x 3.70mm) |
| Height - Seated (Max) | 0.154"" (3.90mm) |
| Capacitance | 4.7 µF |
| Voltage - Rated | 16 V |
| Impedance | 26 Ohms |
| Ripple Current @ High Frequency | 13.5 mA @ 10 kHz |
