2222 025 17479
CAP ALUM 47UF 20% 450V AXIAL THManufacturer: Vishay Beyschlag/Draloric/BC Components
Categories: Aluminum Electrolytic Capacitors
Quality Control: Learn More
Vishay Beyschlag/Draloric/BC Components 025 AMR series aluminum electrolytic capacitor, part number 2222-025-17479. This axial, can type component offers a capacitance of 47 µF with a ±20% tolerance and a rated voltage of 450 V. Featuring an Equivalent Series Resistance (ESR) of 3.39 Ohms at 100 kHz and an impedance of 1.65 Ohms, it is designed for general-purpose applications. The capacitor provides a ripple current handling capability of 518 mA at 10 kHz and 370 mA at 100 Hz. It is rated for a lifetime of 3000 hours at 85°C and operates within a temperature range of -40°C to 85°C. The physical dimensions are 0.630 inches (16.00 mm) in diameter and 1.575 inches (40.00 mm) in length. This through-hole mounting component is supplied in bulk packaging.
Additional Information
Series: 025 AMRRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Bulk |
| Package / Case | Axial, Can |
| Size / Dimension | 0.630"" Dia x 1.575"" L (16.00mm x 40.00mm) |
| Polarization | - |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | - |
| Ratings | - |
| ESR (Equivalent Series Resistance) | 3.39Ohm |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Surface Mount Land Size | - |
| Height - Seated (Max) | - |
| Capacitance | 47 µF |
| Voltage - Rated | 450 V |
| Impedance | 1.65 Ohms |
| Ripple Current @ Low Frequency | 370 mA @ 100 Hz |
| Ripple Current @ High Frequency | 518 mA @ 10 kHz |
