VSFNP71T92WCGWSM
SSD 1.92TB M.2 TLC NVME 3.3VManufacturer: Viking Technology
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Viking Technology VSFNP71T92WCGWSM is a 1.92TB M.2 NVMe Solid State Drive module utilizing TLC NAND flash memory. This component operates at a 3.3V supply voltage and conforms to the M.2 22110 form factor, measuring 110.00mm x 22.00mm x 4.60mm. It delivers sequential read speeds of up to 2.0GB/s and sequential write speeds of up to 1.2GB/s. The operating temperature range for this drive is 0°C to 70°C. This high-capacity, high-performance NVMe SSD is suitable for demanding applications in data centers, enterprise storage, and high-performance computing.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Size / Dimension | 110.00mm x 22.00mm x 4.60mm |
| Memory Size | 1.92TB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (TLC) |
| Type | NVMe |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3.3V |
| Current - Max | - |
| Form Factor | M.2 Module |
| Speed - Read | 2.0GB/s |
| Speed - Write | 1.2GB/s |
