PI3749-00-LGIZ
IC REG BUCK-BOOST ADJ 10A 108LGAManufacturer: Vicor Corporation
Categories: DC DC Switching Regulators
Quality Control: Learn More
The Vicor Corporation PI3749-00-LGIZ is an advanced buck-boost switching regulator designed for high-current, efficient power conversion. This 10A adjustable output device operates with a switching frequency of 800kHz, offering a versatile step-up/step-down functionality. Featuring a positive adjustable output configuration, it supports output voltages up to 34V and a fixed 12V output. The PI3749-00-LGIZ integrates a synchronous rectifier for enhanced efficiency. It is housed in a compact 108-LGA (14x10) module, suitable for surface mount applications. The operating temperature range is -40°C to 115°C (TJ). This component is utilized in demanding applications across various industries, including telecommunications, industrial automation, and high-performance computing.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 108-BLGA Module |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up/Step-Down |
| Current - Output | 10A |
| Operating Temperature | -40°C ~ 115°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 800kHz |
| Voltage - Input (Max) | 34V |
| Topology | Buck-Boost |
| Supplier Device Package | 108-LGA (14x10) |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | 34V |
| Voltage - Input (Min) | 16V |
| Voltage - Output (Min/Fixed) | 12V |
