productimage

PI3543-00-BGIZ

IC REG BUCK 10A 85BGA

Manufacturer: Vicor Corporation

Categories: DC DC Switching Regulators

Quality Control: Learn More

Vicor Corporation PI3543-00-BGIZ is a high-performance buck switching regulator IC designed for demanding power delivery applications. This module provides a 10A output current with a selectable output voltage range from 2.6V to 3.6V, featuring a fixed 3.3V option. Operating with an input voltage range of 36V to 60V, the PI3543-00-BGIZ utilizes a 400kHz switching frequency and incorporates synchronous rectification for enhanced efficiency. Its 85-BGA (10.5x10.5) package is suitable for surface mount applications and operates across an industrial temperature range of -40°C to 125°C. This component is frequently employed in high-density power systems, data center infrastructure, and advanced industrial automation.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:
Technical Details:
PackagingTray
Package / Case85-BBGA Module
Output TypeAdjustable (Fixed)
Mounting TypeSurface Mount
Number of Outputs1
FunctionStep-Down
Current - Output10A
Operating Temperature-40°C ~ 125°C (TJ)
Output ConfigurationPositive
Frequency - Switching400kHz
Voltage - Input (Max)60V
TopologyBuck
Supplier Device Package85-BGA (10.5x10.5)
Synchronous RectifierYes
Voltage - Output (Max)3.6V
Voltage - Input (Min)36V
Voltage - Output (Min/Fixed)2.6V (3.3V)
