COGS-12264-12C-FC-G-LV
LCD MOD 24DIG 12X2 TRANSFLECTIVEManufacturer: Varitronix
Categories: LCD, OLED Character and Numeric
Quality Control: Learn More
Varitronix COGS-12264-12C-FC-G-LV is a character display module featuring a 12 x 2 character format with 24 total characters. This STN – Super-Twisted Nematic display utilizes a transflective mode, offering visibility in both ambient and direct light conditions without requiring a backlight. The character format is 5 x 8 dots, with individual dot dimensions of 0.50mm W x 0.50mm H and character dimensions of 3.55mm H x 2.20mm W. Communication is facilitated via an I2C interface. The module operates within a temperature range of -5°C to 50°C and requires a supply voltage of 5V. This component is suitable for applications in industrial control, consumer electronics, and portable instrumentation.
Additional Information
Series: -RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Display Type | STN - Super-Twisted Nematic |
| Display Mode | Transflective |
| Backlight | Without Backlight |
| Interface | I2C |
| Operating Temperature | -5°C ~ 50°C |
| Voltage - Supply | 5V |
| Viewing Area | 33.00mm L x 14.50mm W |
| Character Size | 3.55mm H x 2.20mm W |
| Display Format | 12 x 2 |
| Character Format | 5 x 8 Dots |
| Dot Size | 0.50mm W x 0.50mm H |
| Outline L x W x H | - |
| Text Color | - |
| Background Color | - |
| Number of Characters | 24.0 |
