9C-8.000MEEJ-T
CRYSTAL 8.0000MHZ 18PF SMDManufacturer: TXC CORPORATION
Categories: Crystals
Quality Control: Learn More
8 MHz ±10ppm Crystal 18pF 80 Ohms HC-49/US
Additional Information
Series: 9CRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | HC-49/US |
| Load Capacitance | 18pF |
| Size / Dimension | 0.449"" L x 0.189"" W (11.40mm x 4.80mm) |
| Mounting Type | Surface Mount |
| Type | MHz Crystal |
| Operating Temperature | -20°C ~ 70°C |
| Frequency Stability | ±10ppm |
| Frequency Tolerance | ±10ppm |
| Operating Mode | Fundamental |
| Ratings | - |
| Height - Seated (Max) | 0.161"" (4.10mm) |
| ESR (Equivalent Series Resistance) | 80 Ohms |
| Frequency | 8 MHz |
