7A-12.000MAAJ-T
CRYSTAL 12.0000MHZ 18PF SMDManufacturer: TXC CORPORATION
Categories: Crystals
Quality Control: Learn More
12 MHz ±30ppm Crystal 18pF 80 Ohms 2-SMD, No Lead
Additional Information
Series: 7ARoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, No Lead |
| Load Capacitance | 18pF |
| Size / Dimension | 0.197"" L x 0.126"" W (5.00mm x 3.20mm) |
| Mounting Type | Surface Mount |
| Type | MHz Crystal |
| Operating Temperature | -20°C ~ 70°C |
| Frequency Stability | ±30ppm |
| Frequency Tolerance | ±30ppm |
| Operating Mode | Fundamental |
| Ratings | - |
| Height - Seated (Max) | 0.053"" (1.35mm) |
| ESR (Equivalent Series Resistance) | 80 Ohms |
| Frequency | 12 MHz |
Request a Quote
