OPB862P51
SENSOR OPT SLOT PHOTOTRANS MODULManufacturer: TT Electronics/Optek Technology
Categories: Transistor Output
Quality Control: Learn More
TT Electronics/Optek Technology OPB862P51 is a through-beam optical sensor module featuring a phototransistor output. This component is designed for precise object detection with a sensing distance of 0.125 inches (3.18mm). It operates with a maximum collector current (Ic) of 30 mA and a maximum DC forward current (If) of 50 mA. The module offers a collector-emitter breakdown voltage of 30 V. Mounting is facilitated via a chassis mount. The OPB862P51 is supplied in bulk packaging and is operational across a broad temperature range of -40°C to 85°C. This sensor is commonly utilized in industrial automation, security systems, and office equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module, Pre-Wired |
| Sensing Distance | 0.125"" (3.18mm) |
| Sensing Method | Through-Beam |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Phototransistor |
| Response Time | - |
| Current - Collector (Ic) (Max) | 30 mA |
| Voltage - Collector Emitter Breakdown (Max) | 30 V |
| Current - DC Forward (If) (Max) | 50 mA |
