OPB390P11
SENSOR OPT SLOT PHOTOTRANS MODULManufacturer: TT Electronics/Optek Technology
Categories: Transistor Output
Quality Control: Learn More
TT Electronics/Optek Technology OPB390P11 is a through-beam optical sensor with a phototransistor output. This module features a 0.125" (3.18mm) sensing distance and is pre-wired for ease of integration. Designed for robust performance, it operates with a maximum collector current (Ic) of 30 mA and a maximum DC forward current (If) of 50 mA. The device boasts a collector-emitter breakdown voltage of 30 V. Its chassis mount design ensures secure installation in a variety of applications. Operating within a temperature range of -40°C to 85°C, the OPB390P11 is suitable for industrial automation, medical equipment, and office equipment. This component is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module, Pre-Wired |
| Sensing Distance | 0.125"" (3.18mm) |
| Sensing Method | Through-Beam |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Phototransistor |
| Response Time | - |
| Current - Collector (Ic) (Max) | 30 mA |
| Voltage - Collector Emitter Breakdown (Max) | 30 V |
| Current - DC Forward (If) (Max) | 50 mA |
